M118AW41 R0

Panel Type :TFT-LCD
Touch :No
Panel structure :LCM
Application :Automotive Display
Panel size :11.8
Resolution :1200*1600
Vertical Frequency :60Hz
Flip scan :No
Brightness :750 cd/m²
Contrast Ratio :1000:1
Response Time :25
Sunlight Readable :YES
View Angle :85/85/85/85
Color Space :NTSC 70%
Backlight Type :WLED
Backlight Position :Side entry light source
Signal voltage :3.3V
OP Temp. Low :-30 °C
High :85 °C
Backlight Life Time :30,000
Interface Type :LVDS(8bit)
Power Dissipation :9.8W
Display Color :16.7M
Horizontal :194
Vertical :258.55
Depth :6.9/10.6
Backlight voltage :28V
Model:
M118AW41 R0
Weight:
560.000 g

Related Model

Model Version Title PDF
M118AW41 R0 Rev.00 M118AW41 R0 11.8 inch UXGA IPS
Product Category :
Laptop panel
Panel Type:
TFT-LCD
Touch:
No
Panel structure:
LCM
Application:
Automotive Display
Panel size:
11.8
Resolution:
1200*1600
Vertical Frequency:
60Hz
Flip scan:
No
Brightness:
750 cd/m²
Contrast Ratio:
1000:1
Response Time:
25
Sunlight Readable:
YES
View Angle:
85/85/85/85
Color Space:
NTSC 70%
Backlight Type:
WLED
Backlight Position:
Side entry light source
Signal voltage:
3.3V
OP Temp. Low:
-30 °C
High :
85 °C
Backlight Life Time:
30,000
Interface Type:
LVDS(8bit)
Power Dissipation:
9.8W
Display Color:
16.7M
Horizontal:
194
Vertical:
258.55
Depth:
6.9/10.6
Backlight voltage:
28V
Specification
