M097SNX1
Panel Type :TFT-LCD
Touch :No
Panel structure :LCM
Application :Pad & Tablet
Panel size :9.7
Resolution :1024*768
Vertical Frequency :60Hz
Flip scan :No
Signal voltage :3.3V
Power Dissipation :3.36W
Interface Type :LVDS
Brightness :350 cd/m²
Contrast Ratio :900:1
Response Time :20
View Angle :89/89/89/89
Sunlight Readable :No
T-con board :Dorsal fold
Backlight Position :Side entry light source(Bottom)
Backlight Type :WLED
Backlight Life Time :15,000
Backlight voltage :18.0/19.8/21.0V
OP Temp. Low :0 °C
High :50 °C
Horizontal :210.21
Vertical :164.25
Depth :4.8
Color Space :NTSC 53%
Display Color :262K
- Model:
- M097SNX1
- Weight:
- 175.000 g
Related Model
| Model | Version | Title | |
|---|---|---|---|
| M097SNX1 | Rev.00 | M097SNX1 9.7 inch XGA IPS |
- Product Category :
- Laptop panel
- Panel Type:
- TFT-LCD
- Touch:
- No
- Panel structure:
- LCM
- Application:
- Pad & Tablet
- Panel size:
- 9.7
- Resolution:
- 1024*768
- Vertical Frequency:
- 60Hz
- Flip scan:
- No
- Signal voltage:
- 3.3V
- Power Dissipation:
- 3.36W
- Interface Type:
- LVDS
- Brightness:
- 350 cd/m²
- Contrast Ratio:
- 900:1
- Response Time:
- 20
- View Angle:
- 89/89/89/89
- Sunlight Readable:
- No
- T-con board:
- Dorsal fold
- Backlight Position:
- Side entry light source(Bottom)
- Backlight Type:
- WLED
- Backlight Life Time:
- 15,000
- Backlight voltage:
- 18.0/19.8/21.0V
- OP Temp. Low:
- 0 °C
- High :
- 50 °C
- Horizontal:
- 210.21
- Vertical:
- 164.25
- Depth:
- 4.8
- Color Space:
- NTSC 53%
- Display Color:
- 262K
