G190EG01 V0
Panel Type :TFT-LCD
Panel structure :LCM
Touch :No
Application :Industrial
Resolution :1280*1024
Interface Type :LVDS(8bit)
Panel size :19
Vertical Frequency :60Hz
Flip scan :No
Signal voltage :5V
Brightness :450 cd/m²
Contrast Ratio :1000:1
Response Time :3.6/1.4
Color Space :NTSC 72%
View Angle :85/85/80/80
Sunlight Readable :No
T-con board :Dorsal fold
Backlight Position :Side entry light source (top and bottom)
Backlight Type :CCFL
Backlight Life Time :50,000
Backlight voltage :707V
OP Temp. Low :0 °C
High :50 °C
Power Dissipation :26.71W
Display Color :16.7M
Horizontal :396
Vertical :324
Depth :18.5±0.5
- Model:
- G190EG01 V0
- Weight:
- 2400.000 g
Related Model
| Model | Version | Title | |
|---|---|---|---|
| G190EG01 V0 | Ver1.0 | G190EG01 V0 19 inch SXGA TN |
- Product Category :
- GD Panel
- Panel Type:
- TFT-LCD
- Panel structure:
- LCM
- Touch:
- No
- Application:
- Industrial
- Resolution:
- 1280*1024
- Interface Type:
- LVDS(8bit)
- Panel size:
- 19
- Vertical Frequency:
- 60Hz
- Flip scan:
- No
- Signal voltage:
- 5V
- Brightness:
- 450 cd/m²
- Contrast Ratio:
- 1000:1
- Response Time:
- 3.6/1.4
- Color Space:
- NTSC 72%
- View Angle:
- 85/85/80/80
- Sunlight Readable:
- No
- T-con board:
- Dorsal fold
- Backlight Position:
- Side entry light source (top and bottom)
- Backlight Type:
- CCFL
- Backlight Life Time:
- 50,000
- Backlight voltage:
- 707V
- OP Temp. Low:
- 0 °C
- High :
- 50 °C
- Power Dissipation:
- 26.71W
- Display Color:
- 16.7M
- Horizontal:
- 396
- Vertical:
- 324
- Depth:
- 18.5±0.5
- Specification
