B173HAN04.8
Panel Type :TFT-LCD
Panel structure :LCM
Touch :No
Panel size :17.3
Resolution :1920*1080
Interface Type :eDP eDP (2 Lane)
Vertical Frequency :60Hz
Flip scan :No
Signal voltage :3.3V
Brightness :220 cd/m²
Contrast Ratio :800:1
Response Time :25
Color Space :NTSC 45%
View Angle :85/85/85/85
Sunlight Readable :No
T-con board :Straight row
Backlight Type :WLED
Backlight Position :Side entry light source
Backlight Life Time :15,000
Backlight voltage :6.0/12.0/21.0V
OP Temp. Low :0 °C
High :50 °C
Power Dissipation :3.7W
Display Color :16.7M
Horizontal :389.89
Vertical :238.31
Depth :3.3/3.5
- Model:
- B173HAN04.8
- Specification
- View & Download
Related Model
| Model | Version | Title | |
|---|---|---|---|
| B173HAN04.8 | 2A | B173HAN04.8 | |
| B173HAN04.8 | 1A | B173HAN04.8 17.3 inch FHD IPS | View & Download |
| B173HAN04.8 | 3A | B173HAN04.8 17.3 inch FHD AHVA | View & Download |
